CROP TECHNOLOGY GROUP
|
Accessories for compact spinning Machines
|
|
|
|
|
Detailed DescriptionDetailed introduction to suspension clamp:
suspension clamp,cable clamp,clamp
1.Usage:support conductor line and earth line hung on the pole and tower.
2.Features:
Clamp includes rubber block, helical fitting and casting aluminum shell
a. increase the stiffness of mount point and the radius of curvature
b. improve the resist-vibration of clamp,protect the cable well,extend the life.
c. helical structure increase grip strength up to 20% RTS,good dynamic stress
d. Aluminum alloy material, high corrosion and strong mechanical function.
e. rounded in the end, smooth appearance, low corona
f. stress on average,no concentration point
g.the turning direction of the clamp different from the outter ones, the standard configuration is turning right, if turning left,please note it in the contract.
Order Notice:
1.different specification clamp can’t be insteaded
2.suggest to use one time after the clamp afford full strain
3.it must install by professional trained staff.
ecaution:lightning stroke around the circuit.
|
||
CROP TECHNOLOGY GROUP
|
Accessories for compact spinning Machines
|
|
|
|
|
PRODUCT DESCRIPTION:
The "C-spring" and wedge Connector are used to connect
solid and stranded aluminum, alumnum alloy and stranded
aluminum composite conductors including AAC, AAAC,
ACSR, ACAR, AW, ACSR/AW, and ACSS. They may also be
used in non-corrosive environments to connector copper
conductors.
USED MATERIALS:
Aluminum Alloy , Polystyrene Cover
VARIANTS:
The product is manufactured and supplied in modification’s as is showed upwards in Section.
Special range can be required.
STORAGE AND TRANSPORT:
Product do not have any specific requirements on storage. It is fire-resistant and it is not dangerous.
|
||
CROP TECHNOLOGY GROUP
|
Accessories for compact spinning Machines
|
|
|
|
|
PRODUCT DESCRIPTION:
Life Line Connector (LLC) is product with wide range of application. It can be used to replace open pole mounted disconnectors, for connection on tension poles, as short-circuit connector,connection of branching network, and worker protection against accidental re-connecting of disable network.
LLC can be used with all kinds of conductors with range as in table above. When its combined with isolated conductor on Tap side, than it complies with with bird protection requirements and is considered as bird friendly connection.
LLC is constructed for voltage till 36kV and it can be used to connect two medium voltage networks by using Cu or Al isolated conductor on tap side.
The connector can be re-used several times without damaging the wire .
Installation is thanks to low weight easy and fast with Live Line Stick. The guiding lug(1) ensures the guiding of the main wire to the right position, and the wire nut (2) keep stable position on stick during closing and tightening the LLC. That guarantes perfect electrical contact and right positioning on the wire.
Protection against accidental over-tightening is guaranteed by shear heads:
18 Nm of the lower screw, 30 Nm for the ring. Even after the ring is teared off opening is possible thanks to the remaining hexagonal bolt-head screw. On tap side the tear head is calibrated for 13 Nm.
Minimal maintenance needed: only the tightening of the screws needs to be checked periodically.
Operating temperature is -30 / +70 Celsius.
Life time expectation: 35 years.
PRODUCT RANGE: Tap and Main for bare, Cu, Al, *AlFe & ACSR.
CRLLC Main:16-133mm2 <=*110/22 Tap:10-95mm2 =*70/11
CRLLC-BI Main:16-133mm2 <=*110/22 Tap:10-95mm2 ISOLATED =*70/11 since 10/2012
CRLLC2 Main:16-282mm2 <=*240/39 Tap:10-282mm2 =*240/39 since 3/2013
USED MATERIALS:
High strength aluminium alloy for body.
Surface treated aluminium bolt with orque crew heads.
VARIANTS:
The product is manufactured and supplied in modification’s as is showed upwards in PRODUCT RANGE.
PACKING
15pcs per box - Totally 3,6Kg
6 boxes in carton - Totally 22Kg (90pcs)
G.W: 240g/pc.
N.W: 230g/pc.
STORAGE AND TRANSPORT:
Product do not have any specific requirements on storage. Its is fire-resistant and it is not dangerous.
|
||
CROP TECHNOLOGY GROUP
|
Accessories for compact spinning Machines
|
|
|
|
|
PRODUCT DESCRIPTION:
Aluminium parallel groove clamp (PG clamps) are used for connecting two bare conductor or two insulated overhead line. If aerial bundled conductor is insulated, insulation must be striped before installing and than is necessary to install PG cover, who replace insulation.
PRODUCT RANGE:
2PG6-70: 6 – 70mm2 - 14NM
2PG16-15: 16 – 150mm2 - 24NM
3PG35-300: 35 – 300mm2 - 47NM
2PG1-10cu: 1.5–10/16–70 - 10NM
USED MATERIALS:
Electrical aluminium, dacomet finised screws (H.D.G. optionaly)
Cover: UV-resistant plastic
VARIANTS:
Product is produced with 2 different screw coating and with or without cover.
PACKING
TYPE WEIGHT PACKING N.W. DIMENSIONS
(kg) (PCS) (kg) (L*W*H)
2PG6-70 0.08 200 33 340*180*250
3PG16-150 0.22 240 38 460*215*260
2PG35-300 0.45 48 22 120*292*210
2PG1-10Cu 0.1 200 37 340*180*250
STORAGE AND TRANSPORT:
Product don’t have and specific requirements on storage. Its is fire-resistant and its not dangerous.
|
||
CROP TECHNOLOGY GROUP
|
Accessories for compact spinning Machines
|
|
|
|
|
Fuse switch disconnector-verical design CRTRS series used for distribution box, match NH series fuse link, more safe for using.
TRS strip type Fuse switch disconnectors
CRVRS-160/100
CRVRS-160/185
CRVRS-250/185
CRVRS-400/185
CRVRS-630/185
TRS fuse rail is suitable for AC50/60Hz, rated voltage up to 690V, rated current to 630A, 100mm or 185mm barsbar system. For using of the overload and shor circuit.
TRS fuse rail is widely used for transformer station and cable distribution cabinets.
TRS fuse rail according to GB13539.2, GB14048.3, IEC60269.2, IEC60269.3 standard.
CRVRS-160/100
CRVRS-160/185
CRVHS-250/185
CRVRS-400/185
CRVRS-630/185
|
