CROP TECHNOLOGY GROUP
|
Accessories for compact spinning Machines
|
|
|
|
|
Streamer is installed or mounted on side of xontact and V-Clamp pressing a cable to streamer and it creats electrical connection.Steamer are usually used together with V-clamp to creat electrial connecton between wire and contact.Together it creats very fasr and effective way how to connect cable to various range of low voltage devices such as cabinets,fuse disconnector,bus bar systems and many others.
Product Range
FA-DS-x RM,RE,SM,SE 10-300 0.028 900 23 32x32x25
FA-SS-x RM,RE,SM,SE 10-300 0.014 1600 22.5 36x25x23
D:double
S:single
USED MATERIALS:
AL,brass,copper
VATIANTS:
Variant of the product is also manufactured and supplied in modification's as if showed upwards in PRODUCT RANGE
STORANGE AND TRANSPORT:
Product do not have any specific requirements on storage.It is fire-resistant and it is not dangerous.
|
||
CROP TECHNOLOGY GROUP
|
Accessories for compact spinning Machines
|
|
|
|
|
PRODUCT DESCRIPTION:
V-Clamp consist from profile, or profiled material with one screw and one pad installed on screw.
V-Clamps are usually used together with streamer (prism A8) to create electrical connection between wire
and contact. Streamer is installed or mounted on side of contact and V-clamp pressing a cable to streamer
and it creates a Electrical connection.
Together it create very fast and effective way how to connect cable to various range of low voltage devices
such cabinets, fuse links, fuse disconnector, bus bar systems and many others.
PRODUCT RANGE:
V Clamp FA -VC RM, RE, SM, SE 10-300 mm2 reversible pad
Non reversible V Clamp FA-VCN RM, RE, SM, SE 35-300 mm2 not reversible pad
miniV Clamp FA-mV RM, RE, SM, SE 6-120 mm2
Steel V clamp FA-Fe-VC RM, RE, SM, SE 10-240 mm2
Steel miniV-Clamp FA-Fe-mV RM, RE, SM, SE 6-120 mm2
Stainles mini V Clamp FA-SS-mV RM, RE, SM, SE 6-120 mm2
V-Cover FA-VCover Cover for FA-VC, FA-VCN, FA-Fe-VC
USED MATERIALS:
V-Clamp - Al alloy, Al or brass bridge nickel tinned.
Steel V-Clamp - Fe alloy w. HDG., bridge brass nickel tinned or Fe with HDG.
PACKING: FA-VC(N) FA-mV FA-Fe-VC FA-Fe-mV FA-VCover
Carton dimm : 42x33x25 60x30x20 38x28.5x32 30x22x17 45x29.5x31.5
Contain: 500pcs 500pcs 500pcs 500pcs 500pcs
Each clamp: 69g 25g 69g 42g 22g
Netto: 32kg 32kg 34kg 20kg 10kg
Brutto: 33kg 33kg 34.5kg 21kg 11kg
STORAGE AND TRANSPORT:
Product do not have any specific requirements on storage. It is fire-resistant and it is not dangerous.
|
||
CROP TECHNOLOGY GROUP
|
Accessories for compact spinning Machines
|
|
|
|
|
Strain clamps are used to fix conductor and ground wire through insulators or link fittings to tower arms or substation structures. In according to the clamp construction and mounting way, the clamps include two types as compression type and bolt, and the compression type include hydraulic and explosive, type. Strain clamps fit for steel wire, aluminium conductor, AS,ACSR/AS conductor, shielding wire, etc. compressive strain clamps are usually made of malleableiron orcastingsteel.
The slip strength of this type must be not less than 65% of the rated strength of conductor. While bolt type strain clamps are often made of aluminium and alloy material, so their slip strengthmust be not less than 65% of the rated strength of conductor.
We can supply all kind of Strain Clamps including :
dead end clamp for ACSR conductor(compression type ) ,
compression dead end clamp ,
dead end clamp for ACSR conductor(hydraulic type ) ,
aluminium alloy strain clamp (bolted type),
malleable iron strain clamp ,
strain clamp (bolted type),
aluminum alloy strain clamp (straight line type),
stain clamp (straight line type )
|
||
CROP TECHNOLOGY GROUP
|
Accessories for compact spinning Machines
|
|
|
|
|
Anchor Clamp | Tension Clamp
Four Core Anchor clamps are design to anchor self supporting LV.ABC from 2 to 4 cores, the
wedge can be self-adjusting. Pilot wires or street lighting conductor are led alongside the clamp.
The self opening is featured by an integrate spring facilities for easily insert the conductor in to
the clamp.
PRODUCT RANGE:
Type Cross Section(mm2) Weight(kg)
2AN10.35 OLD 10-35 0.108
4AN10.35 OLD 10-35 0.118
2AN10.35OY 0-35 0.110
4AN10.35 OY 10-35 0.120
USED MATERIALS:
Hi-conductivity aluminium UV & fire resistant plastic, hot dip galvanized steel stripe.
VARIANTS:
The product is manufactured and supplied in this form only.
PACKING:
Standard package for transport. or according to customer requirment.
STORAGE AND TRANSPORT:
Product don’t have and specific requirements on storage. Its is fire-resistan and its not dangerous
|
||
CROP TECHNOLOGY GROUP
|
Accessories for compact spinning Machines
|
|
|
|
|
Full range of ABC Insulation Piercing Connectors used to tap off low voltage XLPE insulated Aerial Bundled Cable (ABC)
-Featuring a unique insulation piercing technique
-Designed for all weather applications and easy to install
-Connections can be made live in minutes
-Suitable for Aluminium or Copper
|
