SHY-120 manual multi-functional machine 　ITEM:SHY-120 Name:MANUAL MULTI-FUNCTIONAL MACHINE Punching force:15T Max thickness of sheet:10mm Width of sheet: 120mm weight:approx.50Kg Accessories:3/8"(ф10.5),1/2"(ф13.8),5/8"(ф17),3/4"(ф20.5) Bending(Brass plated) Thickness of sheet:10mm Bending degree:0-90 。 Width of sheet:120mm Cutting(Brass plated) Thickness of sheet:10mm Width of sheet:10-120mm Punching(Brass plated) Thickness of sheet:10mm Round punches:3/8"(￠10.5);1/2(￠13.8);5/8"(￠17);3/4"(￠20.5)

SHY-120H manual multi-unctional machine ITEM:SHY-120H Name:MANUAL MULTI-FUNCTIONAL MACHINE Punching force:15T Max thickness of sheet:10mm Width of sheet: 120mm weight:approx.45Kg Accessories:3/8"(ф10.5),1/2"(ф13.8),5/8"(ф17),3/4"(ф20.5) Bending(Brass plated) Thickness of sheet:10mm Bending degree:0-90 。 Width of sheet:120mm Cutting(Brass plated) Thickness of sheet:10mm Width of sheet:10-120mm Punching(Brass plated) Thickness of sheet:10mm Round punches:3/8"(￠10.5);1/2(￠13.8);5/8"(￠17);3/4"(￠20.5)

VHB-120 multi-function bus processing machine 　The triad busbar processor is user-friendly,good performance in labor and time saving. Lockable castors for easy fixation and move. Pressure gauge for instant watch of the working pressure to prevent accidental overloading. Model VHB-120. Output 20T. Breadth 120mm. Max thickness 10mm. Weight 140kg. Volume:638×485×880mm

MPCB-301V multi-bus processing machine Detailed Description DESCRIPTIONS: 1.function: cutting, punching, horizontal bending, erect bending, conduit bending 2. workbench size: 800mmx 600mm x 770mm (LXWXH) 3. required input power: single phase 220V, 50HZ 4. control voltage: 12V 5. reted working oil pressure: 700kgf/cm2 6. cutting capacity: Cu/A1120mmx12mm 7. punching output: 27tons, 30tons. 8. distance from hole to busbar edge: 65mm, 70mm 9. cutting capacity-copper: dia.14mm-21mm, thickness 10mm dia. 8mm-11mm, thickness 10mm dia. less than 8mm, thickness 8mm.

VHB-200A multi-bus processing machine Detailed Description DESCRIPTIONS: 1.function: cutting, punching, horizontal bending, erect bending, conduit bending 2. workbench size: 800mmx 600mm x 770mm (LXWXH) 3. required input power: single phase 220V, 50HZ 4. control voltage: 12V 5. reted working oil pressure: 700kgf/cm2 6. cutting capacity: Cu/A1120mmx12mm 7. punching output: 27tons, 30tons. 8. distance from hole to busbar edge: 65mm, 70mm 9. cutting capacity-copper: dia.14mm-21mm, thickness 10mm dia. 8mm-11mm, thickness 10mm dia. less than 8mm, thickness 8mm.
