Wide range of applications: 　Applied to sectors of higher requirements of depth, smoothness, areas, such as jewelry marking, paper packaging marking, auto parts marking, electronic hardware marking, sanitary ware marking, glass marking, and bitmap marking. They can make standard and colorful pictures on the surface of metal and plastic. 　 Parameter: Average output power: 20W Laser wavelength: 1060nm Laser output power: 20KHZ-80KHZ continuously adjustable Power Supply: Single Phase AC 90-260V/50HZ-60HZ Electricity power: <160W Size: 570mm * 270mm * 200mm Total Weight: <22KG Focus spot size: <0.01mm Marking Speed: 30mm/30mm-300mm/300mm optional Marking area: >800 standard characters / second Semiconductor module life: >500,000 hours Computer operating system: Win98/Win2000/XP Cooling method: Built-in air-cooled Control Interface: Standard USB

Products: The semiconductor side of pump laser marking machine is also often referred to as the semiconductor side-pumped YAG laser marking machine or a diode side-pumped YAG laser marking machine. Semiconductor marking machine use semiconductor laser diode-pumped Nd: YAG medium of 808nm wavelength, and the medium produced a large number of inverted particles which formed giant pulsed laser output of 1064nm wavelength under the action of Q switching, so the electro-optical conversion is efficient. Through the computer-controlled galvanometer mirror, the laser beam can change the optical path, thus to realize the automatic marking.

Model Features 　　Its outputting laser spots is small, marking line is thin. The beam quality is high, output laser is stable, and it is easier to debug the marking. High frequent laser makes it more suitable for a number of non-metallic materials and the speed of marking faster. It is small-sized, and there is no need to access external water cooling equipments. Overall machine has stable performance; slight volume, and low power consumption. Application of materials and industries 　　Compared with side-pump YAG marking machine, its pulse width is narrower, the width of sculpture line is uniform and fine, which are suitable for marking a variety of non-metallic materials. It is suitable for some occasions requiring more sophistication and more accuracy. Some electronic components, plastic buttons, integrated circuits (IC), electrical appliances, mobile communications and other industries are applicable.

Applications: sculpturing of metal and a variety of non-metallic materials. You can mark any text and images. Marking the different parameters of the software will come up with different marking effect. This issue should be specifically treated, also marks a number of non-metallic items, but not all. Crafts class effect can be achieved. With the corresponding components, can achieve rotation marking, flight marking (continuous markers), split marking (large format tags). It can mark text and fills, vector (line diagram), bitmap (photo), all kinds of bar codes, all kinds of serial number. Support the number and time of self-hop set. Itself a lot of graphics and text can be edited. Applications: 　　electronics, telecommunications, electrical appliances, instruments, tools, precision instruments, various keyboards, jewelry, watch glasses, hardware, plumbing, building materials, auto parts, chips and so on. Widely used in electric vehicle frame, motorcycle frame, tourism trailers, golf carts and other metal frame materials, coding and product the Uniform Code. Application materials include: a variety of metals, metal oxides, glass, plastic, etc. Widely used in automobile, motorcycle parts, aerospace components, integrated circuit chips, food, beverages and tobacco packaging, the phone keypad, battery, electronic components, computer parts and peripherals, hardware tools, stainless steel appliances, electrical appliances, communication products , medical equipment, sanitary ware, watches and clocks jewelry, industrial bearings, wire and cable, clothing accessories and many other fields of graphics and text markup.In the metal (including metals), electroplating materials, coating materials, coating materials, plastics, rubber, resin, ceramic and other materials on the tag beautiful image.

Applications: 　　　They can be applied to metals, alloys and oxides, ABS, epoxy resin, printing ink and so on. They are also widely used in electronic components, electrical appliances, jewelry, spectacles, hardware, auto parts, telecommunication products, plastic buttons, integrated circuits (IC) industries etc. Application areas: 　　　They are widely used to mark graphics and text in automobile, motorcycle parts, aerospace components, integrated circuit chips, food, beverages and tobacco packaging, the phone keypad, battery, electronic components, computer parts and peripherals, hardware tools, stainless steel implement, electrical appliances, communication products, medical equipments, sanitary ware, watches, jewelry, industrial bearings, wire and cable, clothing accessories and many other fields.
