The uses of gypsum grinding mill:
gypsum ultrafine grinding mill is mainly used in mining, building materials, chemical, metallurgical and other industries. It can process stone materials that moisture content less than 5%, Mohs hardness under 6 levels, such as kaolin, limestone, talc, barite, dolomite, calcite, marble, gypsum, bentonite, mica, graphite, and so on. The finished powder size can be 3000meshs.
HGM series gypsum grinding mill is the technology team of Shanghai Clirik machine Co., LTD through long-term research about gypsum characteristics, and field investigate production process of gypsum processing factory, overcome varies problems appeared in the process of gypsum making, developed new generation grinding equipment. The gypsum grinding equipment is the result of our technical staff after years accumulated experience and test innovative, it can be used not only for gypsum powder processing, can also be used to manufacture calcite, barite, marble and other stone materials. It also has many appellations, such as calcite mill, barites mill, calcium carbonate mill, mica mill, dolomite mill. Gypsum grinding mill is the preferred stone machining equipment.
Features of gypsum grinding mill:
1. High efficiency
Under the same final size and power, the product capacity of ultrafine mill is twice than jet mill and agitation mill.
2. Longer lifetime of spare parts
The roller and ring are made of special material, which improve the grinding efficiency a lot. For same material and final size, the lifetime of its wearing parts can reach to more than one year, about 2-5 times as long as that of vertical shaft impact crusher and turbo-mill. Especially when handling calcium carbonate and calcite, the lifetime can reach 2-5 years.
3. High safety and reliability:
There are no rolling bearings and bolts in grinding cavity, so problems caused by bolts shedding or wear of bearings and seal components will never happen.
4. High fineness of products
The product fineness can reach D97≤5μm.
5. Environment friendly
The application of pulse dust collector and muffler reduce the pollution and noise of the dust, which has reached national environment protection standard.
Working principle of gypsum grinding mill:
The main bearing and each dial are driven by electromotor of main machine through reducer, and numbers of rollers, which are rolling in the ring, are driven by dial through plunger. After crushed by hammer crusher, the big materials become small ones and are sent to storage hopper by elevator and further sent to the middle of first dial evenly by the electromagnetic vibrating feeder and feeding pipe. The materials will be driven to the edge of dial by centrifugal force and fall down into the ring, crushed and grinded by roller, and become powder after production of three rings. The high pressure centrifugal blower will inhale air from outside and blow the crushed materials to classifier. The rotating turbo in the powder concentrator will make the coarse material return to the mill and reground, while the fineness will mix with the air and go into the cyclone and be discharged in the discharge bin, which is at the bottom of it. The air, which mixed with very little fineness, will be purified by impulse duster and discharged by blower and muffler.
